SW-10KW wind turbine generator

Rotor diameter:

7.0m

Blades quantity:

3pcs

Direction:

always upwind

Blades material:

Glass fiber reinforced plastic

Rated output Power:

10Kw, 10000W

Maximum output Power:

13000W

working voltage:

DC240/500V,AC220V/380V

Annual average energy production:

20MWH (in rate 5m/s wind speed)

working wind speed:

3-25m/s

Initial wind speed:

3.0m/s

Nominal wind speed:

10.0m/s（22.3mph）

Storm-stand:

up to 55m/s

Max rotate speed:

180r/min

Wind turbine type:

Three-phase, PMG Alternator

Working temperature:

from -40 to +60 C

Blade Pitch Control

Fixed Pitch

Over Speed Protection

Auto-furl

Speed regulation methods:

Yawing and electrical magnet switch

Stop Methods

Manual Brake + Hydraulic Brake+ Auto Brake

Gearbox:

None, Direct Drive

Batttery full charge time:

about 8 hours
