SWT-5KW wind turbine generator

Rotor diameter:

5.6m

Blades quantity:

3pcs

Direction:

always downwind

Blades material:

Glass fiber reinforced plastic

Rated output:

5000W

Maximum output:

5400W

working voltage:

DC240V/400V,AC220V

Annual average energy production:

11880KWH (in rate 5m/s wind speed)

working wind speed:

3-30m/s

Initial wind speed:

3.0m/s

Nominal wind speed:

10.5m/s（35.5mph）

Storm-stand:

up to 60m/s

Max rotate speed:

240r/min

Wind turbine type:

Three-phase, PMG Alternator

Working temperature:

from -40 to +60 C

Blade Pitch Control

Variable Pitch

Stop method

Positivity Blade Pitch

Speed regulation methods:

Passivity Pitch

Gearbox:

None, Direct Drive

Battery charge time:

about 8 hours
